Step into the future of presentations with the NEC P554U. Tailored to transform lectures and meetings, it merges crystal-clear visuals with unparalleled brightness. Set to redefine your projection experience, it seamlessly fits into previous setups, promising not just brilliance but also ease and efficiency.


  • Uncompromised Brightness: A staggering 5,300 ANSI lumen ensures every slide and video stands out, even in well-lit rooms.
  • Longevity Meets Clarity: Benefit from a smooth operation over five years*, thanks to our long-lasting lamp life combined with patented LCD panel dust protection.
  • Effortless Replacement: If you're transitioning from an older model, the NEC P554U has got you covered. Its mounting options and zoom capabilities match previous models, ensuring a hassle-free swap.
  • Vivid Imagery: Dive into natural colors with the high contrast that LCD technology provides, transforming every presentation into a visual treat.

Top Benefits:

  • Big Screen, Small Investment: With its affordable pricing, the NEC P554U is perfect for venues from corporate boardrooms to university auditoriums.
  • Simplified Installation: A wide horizontal and vertical lens shift coupled with versatile projection features means a setup that’s as easy as plug-and-play.
  • Economical Excellence: With low power consumption, this projector promises reduced operational costs and a lowered carbon footprint.
  • Empower Collaboration: Boost the interactivity of your sessions. With the NEC MultiPresenter option, share content from up to 16 devices. And here’s the kicker: No extra power source needed!
  • Centralized Control: Using NaViSet Administrator 2, administer all connected NEC devices from one hub. It’s efficiency redefined.
  • Future-Ready Connectivity: The NEC P554U isn’t just for today. Its advanced connectivity ensures it’s an asset for tomorrow too.

Best Suited For:
Educational institutions, corporate boardrooms, seminars, and any space that demands a premium projection experience.

Final Thoughts:
In a world where clarity matters and engagement is key, the NEC P554U stands out as the gold standard in projection. It’s not just a tool, but a partner in bringing ideas to life. When you choose the NEC P554U, you’re choosing more than just a projector; you’re opting for an experience. Elevate your presentations today.



Projection Technology 3LCD Technology
Native Resolution 1920x1200
Contrast Ratio (typ.) 20000:1
Brightness [Lumen] 5300
Light Source Lamp
Lamp Life 4000
Lens F= 1.5–2.08, f= 17.2–27.7 mm
Lens shift H:±0.15, V:+0.55,-0
Keystone correction +/- 15° manual horizontal / +/- 30° manual vertical projection
n Factor 1.2 – 2 : 1
Projection Distance [m] 0.8 – 12.9
Screen Size (diagonal) [cm] / [inch] Maximum: 762 / 300"; Minimum: 76 / 30"
Zoom 1 - 1.6; Manual
Focus Adjustment Manual
Supported Resolution Up to 1920 x 1200 (WUXGA)
Horizontal Frequency [kHz] 15 – 100 kHz (RGB: 24 kHz)
Vertical Frequency [Hz] 50 – 120 Hz
RGB (analog) Input 1 x Mini D-sub 15 pin
RGB (analog) Output 1 x Mini D-sub 15 pin
Digital Input 1 x HDBaseT; 2 x HDMI™ (Deep Color, Lip sync) with HDCP
Audio Input 1 x 3.5 mm Stereo Mini Jack for Computer analog; 1 x RCA Stereo for Video and S-Video; 2 x HDMI audio
Audio Output 1 x 3.5 mm Stereo Mini Jack (variable)
Video Input 1 x RCA
Control Input 1 x D-Sub 9 pin (RS-232) (male)
LAN 1 x RJ45
USB 1 x Type A (USB 2.0 high speed); 1 x Type B
Video Signals NTSC 3.58; NTSC 4.43; PAL; PAL-M; PAL-N; PAL60; SECAM
Remote Control
Remote Control Aspect Ratio; Audio Control; Auto Adjust; Eco Mode Control; Freeze-function; Help-function; ID set; Keystone Correction; Magnify-function; Page (up, down); Picture Adjust; Picture Mute; Power (On-OFF); Presentation and Mouse Control; Select (up, down, left, right); Source Select
Power Supply 100-240 V AC
50/60 Hz
Power Consumption [W] 400-500
Dimensions (W) [mm] 420
Dimensions (H) [mm] 133
Dimensions (D) [mm] 322
Weight [kg] 3-5
Fan Noise [dB (A)] 34 / 37 (Eco / Normal)
Environmental Conditions
Operating Temperature [°C] 5 to 40
Operating Humidity [%] 20 to 80
Storage Temperature [°C] -10 to 50
Storage Humidity [%] 20 to 80
Safety and Ergonomics CE
Speakers [W] 1 x 20 (mono)
Additional Features
Special Characteristics Auto Eco Mode; Auto Power ON/OFF; Carbon Savings Meter; Contrast Ratio 20000:1 with Iris; Control ID Function; DICOM simulation; Direct Power-Off Function; Help Function; HTTP Browser Control; Kensington security slot; Keypad Lock; Lens Shift (vertical 0 max/55 max, horizontal ± 15 max.); Magnify; Manual Wall Color Correction; NaViSet Administrator 2; Off-Timer; Optional User Logo; OSD with 27 languages; Password Security System; Pincushion Correction; Quick Start; Test Pattern; Unique Power Saving Functions; Virtual Remote for direct PC control green
n Features
Energy Efficiency 0.4W Power save mode
Auto ECO Mode
Green one-touch ECO and AV mute button
Ecological Materials Downloadable manuals
ECO packaging
Ecological Standards ErP compliant
RoHs compliant
Projector Warranty 5 years Warranty
Light Source Warranty 6 months, max. 1000 hrs
Shipping Content
Shipping Content Power Cable
Remote Control
User Manual
Quick Setup Guide
Utility Software
Mini D-SUB Signal Cable (1.8 m)
Optional Accessories
Optional Accessories Cable Cover (NP12CV)
Lamp (NP44LP)
Barcode # 5028695613157
Brand NEC
Shipping Weight 4.8000kg
Shipping Width 0.400m
Shipping Height 0.400m
Shipping Length 0.300m
Shipping Cubic 0.048000000m3
