A wide array of connectivity options plus PointWrite? and QWrite interactive features (optional) make the MW824ST a complete classroom interactive projector solution. A short-throw ratio, 13000:1 ultra-sharp contrast ratio, 3200 ANSI Lumens brightness and long lamp life ensure vibrant, reliable visual performance time and again. Also, featuring MHL function, it allows you to show the content from your Android devices to the big screen.
As the first DLP brand to incorporate Philips' ImageCare technology into its projector lamp system, BenQ has taken a further leap, developing its own SmartEco Technology to perfect what DLP can do for energy saving in the 21st century classroom. Built with this brand new invention, the MW824ST brings together uncompromised brightness, exquisite picture quality and optimized lamp life through innovative features.
The SmartEco Mode, which cleverly adjusts the lamp power to maximize power saving by delivering the best contrast and brightness performance using only as much light as needed.
The LumenCare Mode, which adjusts projector lamp power in gain steps until full power is reached, effectively maximizes power saving and reduces brightness decay. It’s the first and only projection feature on market that ensures three years of consistent image brightness for optimal learning and teaching.
No Source Detected Mode
The automatic switch to Eco Blank Mode after the projector is turned on for over three minutes without a display source, eliminating unnecessary energy waste and prolonging the life of the projector lamp.
Good Things Come in Short Distance
With MHL connectivity, you can share your content from your Android devices on big screen. MW824ST features MHL function and allows you to mirror the data, photo and other contents from your android devices to big screen, Also, your device is being charged while you're using it, you don't have to worry about the power while presenting.
Blu-ray Full HD 3D Supported
BenQ MW824ST is built with latest DLP® technology to support 3D functionality, allowing schools to bring an immersive learning experience to their students with a simple preparation of 3D glasses and 3D content from your blu-ray player.
Razor-Sharp Clarity with Ultra-Readability
Enabling a 96% fill factor, DLP Technology supplies pixel circuitry behind the pixel, thereby eliminating the thick dark bezels around individual pixels, which diminish color and detail. A higher fill factor and less black border translate to noticeably purer, more intense color and smoother image quality.
Even in lit venues, BenQ DLP Projectors achieve the optimal balance of brightness and color accuracy, with BrilliantColor™ Technology additionally boosting true-to-life colors that captivate. BrilliantColor enables up to six-color processing by incorporating the secondary colors Yellow, Cyan, and Magenta along with primary Red, Blue, and Green. From intense hues to elusive mid-tones like aqua blues and light yellows, your every presentation is rendered in pure, living splendor.
ecoFACTS can tell you how eco-friendly BenQ products are!
Development of eco-friendly products, BenQ doesn't just want to comply with green regulations passively, but also to actively develop eco-friendly products!
ecoFACTS declares BenQ's greatest efforts on the replacement of hazardous substances, material selection, packaging design, energy-saving design and other aspects of the products.
|Native Resolution||W X GA (1280 X 800)|
|Brightness (ANSI Lumens)||3200 ANSI Lumens|
|Display Color||1.07 Billion Colors|
|Lens||F= 2.8, f = 7.51mm|
|Aspect Ratio||Native 16:10 (5 aspect ratio selectable)|
|Throw Ratio||0.52 (95" @ 1m)|
|Image Size (Diagonal)||Optimization 72"-152", Maximum 300"|
|Lamp Mode (Normal/Economic)*||4000/5000/6500/10000/4000(with 2100 of constant brightness) hours|
|Keystone Adjustment||1D, Vertical ± 30 degrees|
|Projection Offset**||110% ± 5%|
|Resolution Support||VGA (640 x 480) to UXGA (1600 x 1200)|
|Vertical Scan Rate||23-120Hz|
|HDTV Compatibility||480i, 480p, 576i, 576p, 720p, 1080i, 1080p|
|Video Compatibility||NTSC, PAL, SECAM|
|Weight (Without Packing / With Packing)||2.6kg (5.73bs)|
|Dimensions (W x H x D mm)||287.3 x 114.4 x 232.6mm|
|Interface||Computer in (D-sub 15pin) x 2 (Share with component)
Monitor out (D-sub 15pin) x 1
Composite Video in (RCA) x 1
S-Video in (Mini DIN 4pin) x 1
HDMI x 1 (Share with MHL 1.2)
Audio in (Mini Jack) x 2
Audio out (Mini Jack) x 1
Audio L/R in (RCA) x 1
Speaker x 1 (10W)
USB (Type Mini B) x 1
RS232 (DB-9pin) x 1
LAN (RJ45) x 1
|Power Consumption||Normal 290W, Eco 240W Standby < 0.5W|
|Audible Noise (Normal/Economic Mode)||33/28 dBA|
|Power Supply||AC100 to 240 V, 50 to 60 Hz|
|3D Support and Compatibility||Frame Sequential: Up to 720p
Frame Packing: Up to 1080p
Side by Side: Up to 1080i/p
Top Bottom: Up to 1080p
|Picture Modes||Dynamic/Presentation/sRGB/Cinema/(3D)/User 1/User 2|
|On-Screen Display Languages||Arabic/Bulgarian/ Croatian/ Czech/ Danish/ Dutch/ English/ Finnish/ French/ German/ Greek/ Hindi/ Hungarian/ Italian/ Indonesian/ Japanese/ Korean/ Norwegian/ Polish/ Portuguese/ Romanian/ Russian/ Simplified Chinese/Spanish/ Swedish/ Turkish/ Thai/ Traditional Chinese (28 Languages)|
|Accessories (Standard)||Lens Cover
Remote Control w/ Battery
Power Cord (by region)
User Manual CD
Quick Start Guide
Warranty Card (by region)
VGA(D-sub 15pin) Cable
VGA(D-sub 15pin) Cable
Spare Lamp Kit
Lamp in this product contains mercury.
|Unit Of Measure||each|
